SPECIFICATIONS
| Max. Working Height | 18.2 m |
| Max. Platform Height | 16.2 m |
| Max Operating Range | 11.9 m |
| Overall length(Stowed) | 8.44 m |
| Overall Width (Stowed) | 2.3 m |
| Overall Height (Stowed) | 2.49 m |
| Overall Length (Transport) | 8.44 m |
| Overall Width (Transport) | 2.18 m |
| Overall Height (Transport) | 2.29 m |
| Platform Size (LxW) | 1.83×0.76×1.1 m m |
| Turntable Tailswing(Raised) | 0.8 m |
| Tyres | 33x12-20（Solid off-road tyre) |
| Platform Load(Unrestricted/Restricted) | 300 kg |
| Gradeability | 45% |
| Max. Working Slope | X-5°/Y-5° |
| Turret Rotation | 360° Continuous |
| Drive Steering Type | 4WD x 2WS |
| Battery Capacity | 51.2V/304Ah |
| Charger | 48V/60A |
| Hydraulic Oil Tank | 65 L |
| Total Weight | 7300 kg |
