SPECIFICATIONS
| Max. Working Height | 23.8 m |
| Max. Platform Height | 21.8 m |
| Max Operating Range | 16.3 m |
| Overall length(Stowed) | 9.5 m |
| Overall Width (Stowed) | 2.42 m |
| Overall Height (Stowed) | 2.47 m |
| Overall Length (Transport) | 9.5 m |
| Overall Width (Transport) | 2.28 m |
| Overall Height (Transport) | 2.27 m |
| Platform Size (LxW) | 2.4×0.9×1.1 m |
| Turntable Tailswing(Raised) | 1.65 m |
| Tyres | 385/65-24（Solid off-road tyre) |
| Platform Load(Unrestricted/Restricted) | 454/300 kg |
| Gradeability | 40% |
| Max. Working Slope | X-5°/Y-5° |
| Turret Rotation | 360° Continuous |
| Drive Steering Type | 4WD x 2WS |
| Battery Capacity | 48V/460Ah |
| Charger | 48V/80A |
| Hydraulic Oil Tank | 100 L |
| Total Weight | 11070 kg |
