SPECIFICATIONS
| Max. Working Height | 16.8 m |
| Rated Load on Working Platform | 350 kg |
| Overall length/Width | 3.1/1.38 m |
| Max. Platform Height | 14.6 m |
| Min Platform Height | 1.66 m |
| Platform Size (LxW) | 2.28/1.35 m |
| Overall Length | 3.1 m |
| Overall Width | 1.38 m |
| Overall Height (Rails Down) | 1.97 m |
| Drive Speed (Stowed) | 3.4 km/h |
| Drive Speed (Raised) | 0.7 km/h |
| Tire Size | 381 x 127 mm (Solid Non-marking) |
| Turning Radius (Inside/Outside) | 0.3/3.12 m |
| Max.Gradeability | 25% |
| Lift Motor | 24V/3.3kW |
| Rated Load on Working Platform | 350 kg |
| Battery Capacity | 24V/270Ah |
| Charger | 24V/30A |
| Total Weight | 3700 kg |
GALLERY
