SPECIFICATIONS
| Max. Working Height | 7.8 m |
| Rated Load on Working Platform | 230 kg |
| Overall length/Width | 1.85/0.78m |
| Max. Platform Height | 5.8 m |
| Min Platform Height | 0.95 m |
| Platform Size (LxW) | 1.64x0.75 m |
| Overall Length | 1.85 m |
| Overall Width(Transport) | 0.78 m |
| Overall Height (Rails Down) | 1.72 m |
| Drive Speed (Stowed) | 2 km/h |
| Drive Speed (Raised) | 0.3 km/h |
| Tire Size | 356 × 114 mm (Solid Non-marking) |
| Turning Radius (Inside/Outside) | 0.3/1.78 m |
| Max.Gradeability | 30% |
| Lift Motor | 24V/3.3kW |
| Rated Load on Working Platform | 230 kg |
| Battery Capacity | 24V/200Ah |
| Charger | 24V/30A |
| Total Weight | 1520 kg |
