SPECIFICATIONS
| Engine Manufacturer | CUMMINS |
| Rated Power | 129 kW |
| Rated Capacity | 16000 kg |
| Load Center | 500 mm |
| Std Mast | 2-Stage |
| Lift Height | 4000 mm |
| Travel Speed | 23/26 km/h |
| Lift Speed | 0.33/0.41 m/s |
| Lowering Speed | 0.32/0.34 m/s |
| Max. Gradeability | 28/26% |
| Service Weight | 19750 kg |
| Axle Load (Loaded) | Full Load (Front 32555/Rear 9360) kg |
| Axle Load (Unloaded) | Unloaded (Front 3195/Rear 10390) kg |
| Length to fork face | 5374 mm |
| Overall Width | 2537 mm |
| Overall Guard Height | 2900 mm |
| Turning Radius | 4885 mm |
| Ground Clearance | 340/348 mm |
| Max. Fork Height | 4000 mm |
| Carriage Width | 2130 mm |
| Foprk Spread | 470 / 2050 mm |
| Fork Dimensions | 87x200x1500 mm |
| Tire Type | Pneumatic |
| Wheel | 4.0/2.0 |
| Wheelbase | 3500 mm |
| Tire Size(Front/Rear) | 12.00-20-18PR / 12.00-20-18PR |
